Engineered for seamless integration into European-standard piping systems, the OEM Made in China DIN Flanged Gate Valve delivers exceptional reliability, cost-effectiveness, and precise flow isolation.
Manufactured in China's robust industrial supply chain, this valve is designed and produced strictly according to DIN (German National Standard) and EN (European Standard) specifications. It features robust flanged connections (compliant with DIN EN 1092-1) and standardized structural lengths (per DIN 3202), ensuring perfect dimensional compatibility and interchangeability with existing European infrastructure. Backed by our OEM capabilities, this valve provides global buyers with high-quality, customizable solutions at highly competitive costs for municipal water, petrochemical, and heavy industrial applications.
Key Features & Benefits
• Strict DIN/EN Standard Compliance: Designed to meet rigorous DIN 3352 and EN 1984 standards, ensuring perfect compatibility, safety, and performance in European and global industrial projects.
• High Interchangeability: Manufactured with precise structural lengths and flange dimensions, allowing direct replacement of existing valves without pipeline modifications, significantly reducing maintenance costs.
• Cost-Effective OEM Manufacturing: Leveraging China's advanced manufacturing ecosystem, we offer flexible OEM customization (branding, materials, coatings) at highly competitive prices without compromising quality.
• Reliable Flow Isolation: Features a precision-machined wedge gate that drops perpendicular to the flow, providing full-bore flow with minimal pressure drop and zero leakage when fully closed.
• Robust Flanged Connections: Compliant with DIN EN 1092-1 flange standards, ensuring secure, leak-proof bolting and easy installation in diverse pipeline networks.
• Versatile Material Options: Available in cast iron, ductile iron, carbon steel, and stainless steel to suit various media, including water, oil, gas, and corrosive fluids.
Technical Specifications
Parameter | Specification |
Valve Type | Flanged Gate Valve |
Design Standard | DIN 3352 / EN 1984 |
Flange Standard | DIN EN 1092-1 |
Face-to-Face Standard | DIN 3202 |
Body Material | Cast Iron (GG25), Ductile Iron (GGG40), Carbon Steel, Stainless Steel |
End Connection | Flanged |
Pressure Rating | PN6, PN10, PN16, PN25, PN40 |
Size Range | DN50 - DN1200 |
Temperature Range | -10°C to +120°C (Depends on material and seat) |
Operation | Manual Handwheel / Gear Operator / Electric / Pneumatic |
Testing & Inspection | DIN 3230 / EN 12266 / ISO 5208 |
Applications
This high-performance OEM DIN flanged gate valve is widely deployed in:
• Water Supply & Treatment: Municipal water distribution, wastewater treatment plants, and pumping stations.
• Petrochemical & Oil/Gas: Fluid isolation and distribution in processing plants and refineries.
• Power Generation: Cooling water, utility piping, and low-pressure steam systems.
• HVAC & Marine: Industrial heating/cooling networks and shipboard piping systems.
• General Industrial: Any piping network requiring standardized European dimensions and cost-effective OEM sourcing.
FAQ
Q: What does DIN standard mean for gate valves?
A: DIN (Deutsches Institut für Normung) is the German national standard. DIN gate valves are manufactured to precise European dimensional and performance specifications, ensuring high interchangeability, safety, and compatibility across international industrial projects.
Q: Why choose an OEM Made in China DIN valve?
A: Choosing an OEM Made in China valve allows buyers to benefit from China's mature valve manufacturing supply chain, offering significant cost savings (often 30%-50% lower than imported brands) while maintaining strict adherence to DIN/EN standards and offering flexible customization options.
Q: Are DIN flanged gate valves interchangeable with other European valves?
A: Yes. Because they adhere to unified standards like DIN EN 1092-1 for flanges and DIN 3202 for structural lengths, these valves can be seamlessly swapped with other compliant European valves, reducing spare parts inventory and maintenance downtime.
